G36

Maximum mobility with minimum weight

618
Overview Variants Compare
1623

The best technology
Heckler & Koch for Military & Law Enforcement

Calibre 5.56 mm x 45 NATO

Magazine capacity 30 rounds

Maximum effective range up to 300 metres

Performance specifications
High-class down to the smallest detail

  • Capable of withstanding barrel obstructions as per NATO AC225/D14 (steel core, soft core and tracer ammunition)
  • Over-the-beach (OTB) capability
  • The weapon can be set to safety ...

Technical specifications
Precision at a glance.
General
Caliber
5.56 mm x 45 NATO
Operating Principle
Indirect gas-operated
Bolt System
Locked rotating bolt head
Feed Mechanism
Magazine
Magazine capacity
10, 20, 30 Rounds
Cartridge Case Ejection
Right
Modes of Fire
Semi-Auto / Full-Auto
Rate of Fire
750 Rounds/min
Trigger Pull
40 N
Muzzle Velocity -v5-
750 m/s 1
Muzzle Energy -E5-
1125 J 2
Barrel Profile/Twist
Groove/Land Profile, 6 Grooves, Right-Hand Twist
Effective Main Combat Range
300 m
Accurate Suppressive Fire
600 m
Dimensions
Weight

1 Munition: MEN QD 2.0 2 Munition: MEN QD 2.0 3 Magazine, 30 Rounds (empty)

Values rounded. Dimensions and weights may vary depending on the configuration. Subject to technical changes.
