MP5

The world's most popular submachine gun

608
Overview Variants Accessories Compare
1345

The best technology
Heckler & Koch for Military & Law Enforcement

Calibre 9 mm x 19

Magazine capacity 30 cartridges

Performance specifications
High-class down to the smallest detail

  • Extremely reliable, precise and safe-to-use submachine gun, thanks to roller-delayed blowback
  • Capable of withstanding barrel obstructions as per NATO AC225/D14
  • Over-the-beach (...

Technical specifications
Precision at a glance.
General
Caliber
9 mm x 19
Operating Principle
Recoil-Operated
Bolt System
Roller-Delayed Blowback
Feed Mechanism
Magazine
Cartridge Case Ejection
Right
Modes of Fire
Semi-Auto / Full Auto / 3 Round Bursts
Trigger Pull
30 - 45 N
Rate of Fire
800 Rounds/min
Muzzle Velocity -v5-
400 m/s 1
Muzzle Energy -E5-
650 J 2
Barrel Profile/Twist
Groove/Land Profile, 6 Grooves, Right-Hand Twist
Magazine capacity
15, 30 Rounds
Dimensions
Weight

1 Ammunition: MEN DM51 2 Ammunition: MEN DM51 3 Magazine, 30 Rounds (empty)

Values rounded. Dimensions and weights may vary depending on the configuration. Subject to technical changes.

Made for Safety

We want people to be able to live safely. Our products are designed to protect people in free democratic countries from threats and violence. Heckler & Koch is the leading manufacturer of small arms for NATO and EU countries.
